AEROFLEX-IFR 2032 CALIBRATION and AEROFLEX-IFR 2032 REPAIR


A calibration by Custom-Cal is performed by engineers with extensive OEM experience. We have the expertise and the necessary standards to perform the AEROFLEX-IFR 2032 Calibration, onsite calibration may be available. We specialize in quick turnaround times and we can handle expedited deliveries upon request.

Need another Signal Generator?
Shop for Comparable Products on our
 used Signal Generator page


   AEROFLEX-IFR 2032   Description / Specification:
AEROFLEX-IFR 2032 5.4 GHz AM/FM Signal Generator

The Aeroflex 2032 5.4 GHz Signal Generator features a dot matrix display with soft key selected screen options allow flexibility of operation and ease of use. The output may be amplitude, phase, or frequency modulated with pulse modulation available as an option. Modulation is available using a combination of up to two external signal inputs and a built-in LF source. Available options include a second build-in modulation source; avionics modulation (ILS and VOR); pulse modulation; RF level profiling and complex sweep; electronic attenuator. Microprocessor control ensures that the instruments are flexible and easy to use and allows programming by the General Purpose Interface Bus (GPIB). Specifications. Frequency Range: 10 kHz to 5.4 GHz. Indication: 11 digits with annunciators. Resolution: 0.1 Hz. Accuracy: As frequency standard. Phase incrementing: The carrier phase can be advanced or retarded in steps of 1.5° using the rotary control. RF Output Range: -144 dBm to +13 dBm, derated over 4 GHz by 0.1 dB/°C above 40°C.. Indication: 4 digits with unit annunciators. Resolution: 0.1 dB. Harmonics at RF levels up to +7 dBm : Better than -30 dBc for carrier frequencies to 1 GHz; Better than -27 dBc for carrier frequencies to 1.35 GHz, Better than -25 dBc for carrier frequencies above 1.35 GHz. Four modulation modes are available: FM, Wideband FM, phaseM, AM or pulse (optional). Options; 001 - Second modulation oscillator. 002 - Pulse modulation. 003 - High output power. 005 - GMSK Bt 0.3. 006 - Avionics. 008 - RF profiles and complex sweep. 009 - Pulse generator. 010 - DME modulator. 012 - Electronic attenuator. 100 - Single fuse version. 105 - Modified pulse modulator. 112 - EXT MOD 2 input 600 ohm.





Standard Calibration $565.00 *
Click on Logo for More Prices
*This is a Web introductory price for one calibration of the AEROFLEX-IFR 2032. Price does not in most cases include measurement performance data. Pricing does include NIST traceable calibration and issue of a calibration certificate and calibration label. Pricing may vary slightly due to volume and location of laboratory supporting calibration. Volume pricing may apply. On-site fees may apply depending on logistics, location and volume of work to be completed during the visit.


Related Bench Equipment Terms and Definitions. For a complete list go to our  Terms and Definitions Page.

dBm
dBm (sometimes dBmW) is an abbreviation for the power ratio in decibels (dB) of the measured power referenced to one milliwatt (mW). Zero dBm equals one milliwatt. A 3 dB increase represents roughly doubling the power, a 3 dB decrease, the power is reduced by about one half.

Millimeter-wave
Millimeter-wave is a term that generally refers to frequencies of 26.5 GHz and above. That is where signal wavelengths fall below approximately 10 mm, and thus the terminology changes from centimeters to millimeters.

Power Repeatability
Power Repeatability is the random uncertainty in reproducing the power level after changing and re-setting the power level. The power repeatability is ± half the span (in dB) between the highest and lowest actual power. Note: - The long-term power repeatability can be obtained by taken the power repeatability and power stability into account.

Stability
Stability is the extent to which a specified property, characteristic, or parameter of a substance, device, or apparatus, remains fixed with the passage of time or with varying environmental conditions.


Please contact us for your AEROFLEX-IFR 2032 CALIBRATION and/or AEROFLEX-IFR 2032 5.4 GHz AM/FM Signal Generator REPAIR
