KEITHLEY 2410 CALIBRATION and KEITHLEY 2410 REPAIR

A calibration by Custom-Cal is performed by engineers with extensive OEM experience. We have the expertise and the necessary standards to perform the KEITHLEY 2410 Calibration, onsite calibration may be available. We specialize in quick turnaround times and we can handle expedited deliveries upon request.

Need another General Meter?
Shop for Comparable Products on our  used General Meter page


   KEITHLEY 2410   Description / Specification:
KEITHLEY 2410 High-Voltage Source Meter w/ Measurements

The Keithley 2410 High Voltage SourceMeter is a 20W instrument that sources and measures voltage from ± 1 pV to ± 1100V and current from ± 10 pA to ±1A. The higher voltage sourcing range makes it a good choice for resistors and voltage coefficient testing, varistors, and high voltage diodes, including switching, zener, RF diodes, and rectifiers. A 20mA measurement range gives the Model 2410 the extra resolution needed for precision testing of high voltage varistors. SourceMeter units can make standard 4-wire, split Kelvin, and 6-wire guarded ohms measurements, and can be configured for either the constant current or constant voltage method. 0.012% basic accuracy with 5 1/2 digit resolution.





Standard Calibration $285.00 *
Click on Logo for More Prices
*This is a Web introductory price for one calibration of the KEITHLEY 2410. Price does not in most cases include measurement performance data. Pricing does include NIST traceable calibration and issue of a calibration certificate and calibration label. Pricing may vary slightly due to volume and location of laboratory supporting calibration. Volume pricing may apply. On-site fees may apply depending on logistics, location and volume of work to be completed during the visit.


Related Bench Equipment Terms and Definitions. For a complete list go to our  Terms and Definitions Page.

Crest Factor
Crest factor or peak-to-average ratio (PAR) is a measurement of a waveform, calculated from the peak amplitude of the waveform divided by the RMS value of the waveform

Linearity
Linearity is the relative difference between the displayed power ratio, Dx/D0, and the actual (true) power ratio Px/P0 caused by changing the displayed power level from the reference level, D0, to an arbitrary displayed level, Dx.

Phase Noise
Phase noise is the frequency domain representation of rapid, short-term, random fluctuations in the phase of a waveform, caused by time domain instabilities. Phase noise (L(f)) is typically expressed in units of dBc/Hz, representing the noise power relative to the carrier contained in a 1 Hz bandwidth centered at a certain offsets from the carrier.

Sensitivity
Sensitivity is the minimum magnitude of input signal required to produce a specified output signal having a specified signal-to-noise ratio, or other specified criteria.

Please contact us for your KEITHLEY 2410 CALIBRATION and/or KEITHLEY 2410 High-Voltage Source Meter w/ Measurements REPAIR
