TEKTRONIX TDS7254B CALIBRATION and TEKTRONIX TDS7254B REPAIR


A calibration by Custom-Cal is performed by engineers with extensive OEM experience. We have the expertise and the necessary standards to perform the TEKTRONIX TDS7254B Calibration, onsite calibration may be available. We specialize in quick turnaround times and we can handle expedited deliveries upon request.

Need another Oscilloscope?
Shop for Comparable Products on our
 used Oscilloscope page


   TEKTRONIX TDS7254B   Description / Specification:   Spec Sheet
TEKTRONIX TDS7254B 4 Ch 2.5 GHz Digital Phosphor Oscilloscope

The Tektronix TDS7254B 2.5 GHz Digital Phosphor Oscilloscope features exclusive DPX acquisition technology which enables waveform capture rates up to 400,000 wfms/s to quickly find rare glitches in seconds or minutes, instead of hours or days. Innovative software solutions deliver domain expertise for advanced analysis and compliance testing, while the OpenChoice architecture enables users to integrate their expertise through the ability to easily write custom programs or utilize popular commercial software. The intuitive graphical user interface delivers sophisticated capability to advanced users without intimidating occasional users. MyScope control windows allow you to build your own control windows with only the controls, features and capabilities that you care about and are important in your job. For the first time you can create your own personalized “toolbox” of oscilloscope features. No longer do you need to search through menus for features or re-learn how to drive the oscilloscope after a break from the lab. Specifications. Input Channels: 4. Hardware Analog Bandwidth (–3 dB): 2.5 GHz. Rise Time 10% to 90% (typical): 130 ps. Rise Time 20% to 80% (typical): 83 ps. DC Gain Accuracy: ±(2% + (2% x offset). Hardware Bandwidth Limits: Requires TCA-1 MEG. Input Coupling: DC, Gnd. Input Impedance: 50 ohm ±2.5%. Vertical Resolution: 8-Bit (>11-Bit with averaging). Max Input Voltage, 50 ohm: <1 VRMS for <100 mV/div, <5 VRMS for =100 mV/div settings, also determined by TekConnect accessory. Time Base Range: 50 ps/div to 10 s/div. Time Base Delay Time Range: 5 ns to 250 s. Channel-to-channel Deskew Range: ±75 ns. Real-time Sample Rates: 1 channel (max) 20 GS/s, 2 channel (max) 10 GS/s, 3 or 4 channel (max) 5 GS/s. Maximum Record Length per Channel with Standard Memory: 4 Mb (1-CH.), 2 Mb (2-CH.), 1 Mb (4-CH.). Time Resolution (Single-shot): 50 ps (20 GS/s). Max Duration with Standard Memory: 200 µs. Trigger Sensitivity Internal DC Coupled: 0.5 div DC to 50 MHz increasing to 1.5 div at 3 GHz. Display Type: Liquid crystal active-matrix color display, 10.4 in. GPIB Port: IEEE 488.2 standard. Options. 2M - 8 Msamples max, 2 Msamples/ch. 3M - 16 Msamples max, 4 Msamples/ch. 4M - 32 Msamples max, 8 Msamples/ch. 5M - 64 Msamples max, 16 Msamples/ch. DVI - TDSDVI DVI Compliance Test Solution. DVD - TDSDVD Optical Storage Analysis. ET3 - TDSET3 Ethernet Compliance Test Software. JA3 - TDSJIT3 Advanced Jitter Analysis Software. JE3 - TDSJIT3 Essentials. J2 - TDSDDM2 Disk Drive Analysis Software. CP2 - TDSCPM2 ANSI/ITU Telecom Pulse Compliance Testing Software. USB - TDSUSBS USB2.0 Compliance Test S/W Only. SM - Serial Communications Mask Testing. ST - Serial Pattern Trigger. PW3 - TDSPWR3 Power Measurement and Analysis Software. RTE - Serial Data Compliance and Analysis Software.





Standard Calibration $220.00 *
Click on Logo for More Prices
*This is a Web introductory price for one calibration of the TEKTRONIX TDS7254B. Price does not in most cases include measurement performance data. Pricing does include NIST traceable calibration and issue of a calibration certificate and calibration label. Pricing may vary slightly due to volume and location of laboratory supporting calibration. Volume pricing may apply. On-site fees may apply depending on logistics, location and volume of work to be completed during the visit.


Related Bench Equipment Terms and Definitions. For a complete list go to our  Terms and Definitions Page.

Crest Factor
Crest factor or peak-to-average ratio (PAR) is a measurement of a waveform, calculated from the peak amplitude of the waveform divided by the RMS value of the waveform

Linearity
Linearity is the relative difference between the displayed power ratio, Dx/D0, and the actual (true) power ratio Px/P0 caused by changing the displayed power level from the reference level, D0, to an arbitrary displayed level, Dx.

Phase Noise
Phase noise is the frequency domain representation of rapid, short-term, random fluctuations in the phase of a waveform, caused by time domain instabilities. Phase noise (L(f)) is typically expressed in units of dBc/Hz, representing the noise power relative to the carrier contained in a 1 Hz bandwidth centered at a certain offsets from the carrier.

Sensitivity
Sensitivity is the minimum magnitude of input signal required to produce a specified output signal having a specified signal-to-noise ratio, or other specified criteria.


Please contact us for your TEKTRONIX TDS7254B CALIBRATION and/or TEKTRONIX TDS7254B 4 Ch 2.5 GHz Digital Phosphor Oscilloscope REPAIR
