TEKTRONIX TPS2014 CALIBRATION and TEKTRONIX TPS2014 REPAIR


A calibration by Custom-Cal is performed by engineers with extensive OEM experience. We have the expertise and the necessary standards to perform the TEKTRONIX TPS2014 Calibration, onsite calibration may be available. We specialize in quick turnaround times and we can handle expedited deliveries upon request.

Need another Oscilloscope?
Shop for Comparable Products on our
 used Oscilloscope page


   TEKTRONIX TPS2014 (TPS 2014)   Description / Specification:
TEKTRONIX TPS2014

100 MHz Battery Operated Digital Storage Oscilloscope, Four Channel. Sample Rate on Each Channel: 1.0 GS/s. Record Length: 2.5 K points. Battery Operation: Capacity for two hot-swappable battery packs, one standard battery pack offers 4 hours of battery operation. Vertical Resolution: 8 bits (normal or with averaging). Vertical Sensitivity: 2 mV to 5 V/div on all models with calibrated fine adjustment. DC Vertical Accuracy: ±3%. Max Input Voltage (1 M-Ohm): 300 VRMS CAT II at BNC signal to BNC shell, 1000 VRMS CAT II at probe tip to earth ground with optional P5120 passive, high-voltage probe. Position Range: 2 mV to 200 mV/div ±2 V, >200 mV to 5 V/div ±50 V. Bandwidth Limit: 20 MHz. Linear Dynamic Range: ±5 div. Time Base Range: 5 ns to 50 s/div. Time Base Accuracy: 50 ppm. Input Impedance: 1 M-Ohm ±2% in parallel with 20 pF. Input Coupling: AC, DC, GND. Acquisition Modes; Peak Detect: High-frequency and random glitch capture. Captures glitches as narrow as 12 ns typical using acquisition hardware at all time/div settings from 5 µs/div to 50 s/div. Sample: Sample data only. Average: Waveform averaged, selectable: 4, 16, 64, 128. Single Sequence: Use the Single Sequence button to capture a single triggered acquisition sequence at a time. Scan/Roll Mode: At acquisition time base settings of =100 ms/div. Trigger System; Trigger Modes: Auto, Normal, Single Sequence. Trigger Types; Edge (rising or falling): Conventional level-driven trigger. Positive or negative slope on any input. Coupling selections: AC, DC, Noise Reject, HF Reject, LF Reject. Video: Trigger on all lines or individual line, odd/even or all fields from composite video, or broadcast standards (NTSC, PAL, SECAM). Pulse Width (or glitch): Trigger on a pulse width less than, greater than, equal to, or not equal to a selectable time limit ranging from 33 ns to 10 s. Trigger Source: CH1, CH2, Ext, Ext/5, Ext/10. Display: 1/4 VGA, passive color LCD with color on black background with adjustable multilevel contrast and brightness controls.





Standard Calibration $160.00 *
Click on Logo for More Prices
*This is a Web introductory price for one calibration of the TEKTRONIX TPS2014. Price does not in most cases include measurement performance data. Pricing does include NIST traceable calibration and issue of a calibration certificate and calibration label. Pricing may vary slightly due to volume and location of laboratory supporting calibration. Volume pricing may apply. On-site fees may apply depending on logistics, location and volume of work to be completed during the visit.


Related Bench Equipment Terms and Definitions. For a complete list go to our  Terms and Definitions Page.

Crest Factor
Crest factor or peak-to-average ratio (PAR) is a measurement of a waveform, calculated from the peak amplitude of the waveform divided by the RMS value of the waveform

Linearity
Linearity is the relative difference between the displayed power ratio, Dx/D0, and the actual (true) power ratio Px/P0 caused by changing the displayed power level from the reference level, D0, to an arbitrary displayed level, Dx.

Phase Noise
Phase noise is the frequency domain representation of rapid, short-term, random fluctuations in the phase of a waveform, caused by time domain instabilities. Phase noise (L(f)) is typically expressed in units of dBc/Hz, representing the noise power relative to the carrier contained in a 1 Hz bandwidth centered at a certain offsets from the carrier.

Sensitivity
Sensitivity is the minimum magnitude of input signal required to produce a specified output signal having a specified signal-to-noise ratio, or other specified criteria.
