EXFO IQ-2101D CALIBRATION and EXFO IQ-2101D REPAIR

A calibration by Custom-Cal is performed by engineers with extensive OEM experience. We have the expertise and the necessary standards to perform the EXFO IQ-2101D Calibration, onsite calibration may be available. We specialize in quick turnaround times and we can handle expedited deliveries upon request.

Need another Laser Source (DFB-LD-WDM-BBS)?
Shop for Comparable Products on our  used Laser Source (DFB-LD-WDM-BBS) page or new Laser Source (DFB-LD-WDM-BBS) page


   EXFO IQ-2101D   Description / Specification:   Spec Sheet
EXFO IQ-2101D 850 nm Surface-Emitting LED Source Module

The EXFO IQ-2101D Surface-Emitting LED Light Source was designed for optimal stability. It is suitable for laboratory, manufacturing, testing environments, quality control, calibration, acceptance testing, and loss and return loss testing. The IQ-2101D features variable output power over a 6 dB range to simulate power losses with precision. The power can be fine-tuned in increments of 0.1 dB. The IQ-2101D is a module that is housed in the IQ-200 Optical Test System. It operates as a single test unit in the IQ-200 or combines with other test equipment to create a true multi-tasking environment in the IQ-200. Specifications. Wavelength: 850 ±25 nm. Spectral width (FWHM): <= 50 nm. Output power: >= -14 dBm. Stability 15 min. (T = constant): ±0.003 dB. Stability 8 hr. (T = 0° to 50° ±1°C): ±0.03 dB. Temperature sensitivity: <= 0.4 dB. Modulation: 270 Hz, 1kHz, 2kHz (50% duty cycle).





Standard Calibration $220.00 *
Click on Logo for More Prices
*This is a Web introductory price for one calibration of the EXFO IQ-2101D. Price does not in most cases include measurement performance data. Pricing does include NIST traceable calibration and issue of a calibration certificate and calibration label. Pricing may vary slightly due to volume and location of laboratory supporting calibration. Volume pricing may apply. On-site fees may apply depending on logistics, location and volume of work to be completed during the visit.


Related Optical Terms and Definitions. For a complete list go to our  Terms and Definitions Page.

Coherence Length
Average distance over which superimposed waves lose their phase relationships

Linewidth
Linewidth is the width of a spectral line in terms of wavelength, wave number and frequency.

Power Flatness Versus Wavelength
When changing the wavelength at constant power setting and recording the differences between actual and displayed power levels, the power flatness is ± half the span (in dB) between the maximum and the minimum of the measured power levels.

Spectral Width
Spectral Width is the wavelength interval over which the magnitude of all spectral components is equal to or greater than a specified fraction of the magnitude of the component having the maximum value. In optical communications applications, the usual method of specifying spectral width is the full width at half maximum. This is the same convention used in bandwidth, defined as the frequency range where power drops by less than half (at most -3 dB).

Telecom Bands
Optical fiber communications typically operate in a wavelength region corresponding to one of the following Bands. O Band (original): 1260–1360 nm. E Band (extended): 1360–1460 nm. S Band (short wavelengths): 1460–1530 nm. C Band (conventional): 1530–1565 nm. L Band (long wavelengths): 1565–1625 nm. U Band (ultralong wavelengths): 1625–1675 nm


Please contact us for your EXFO IQ-2101D CALIBRATION and/or EXFO IQ-2101D 850 nm Surface-Emitting LED Source Module REPAIR
