A calibration by Custom-Cal is performed by engineers with extensive OEM experience. We have the expertise and the necessary standards to perform the COPPER MOUNTAIN TECHNOLOGIES TR5048 Calibration, onsite calibration may be available.
We specialize in quick turnaround times and we can handle expedited deliveries upon request.
Need another Network Analyzer, SNA, VNA?
Shop for Comparable Products on our
used Network Analyzer, SNA, VNA page
or
new Network Analyzer, SNA, VNA page
More
|
|
|
The Copper Mountain TR5048 is a 4.8 GHz vector network analyzer designed for operation with an external PC. It connects to any Windows-based computer via USB and delivers accurate testing and measurement through a platform that can keep up with constant advancements as well as be remotely accessed. The TR5048 is designed for use in the process of development, adjustment and testing of various electrnonic devices in industrial and laboratory facilities, including operation as a component of an automated measurement system. Specifications. Frequency range: 20 kHz to 4.8 GHz. Impedance: 50 ohm. Test port connector: N-type, female. Number of test ports: 2. Full CW frequency accuracy: ±5x10^ -6. Frequency setting resolution: 10 Hz. Number of measurement points: 1 to 200,001. Measurement bandwidth: 10 Hz to 30 kHz (with 1/1.5/2/3/5/7 steps). Dynamic range (IF bandwidth 10 Hz): From 300 kHz to 4.8 GHz: 120 dB, typ. 123 dB. Accuracy of transmission measurements (magnitude / phase): +5 dB to +10 dB (0.65 dB / 3°), -50 dB to +5 dB (0.55 dB / 3°). Test Port Directivity (without system error correction): 18 dB. Test Port Output Match (without system error correction): 22 dB. Test Port Output Power range: -50 dBm to +5 dBm. Test Port Output Power accuracy: ±1.0 dB. Test Port Output Power resolution: 0.05 dB. Test Port Input Match (without system error correction): 22 dB. Test Port Input Damage level: +23 dBm. Measurement time per point: 200 µs. Measured parameters: S11, S21.
|
