EXFO IQ-1501 CALIBRATION and EXFO IQ-1501 REPAIR

A calibration by Custom-Cal is performed by engineers with extensive OEM experience. We have the expertise and the necessary standards to perform the EXFO IQ-1501 Calibration, onsite calibration may be available. We specialize in quick turnaround times and we can handle expedited deliveries upon request.

Need another Optical Power Meter?
Shop for Comparable Products on our  used Optical Power Meter page or new Optical Power Meter page


   EXFO IQ-1501   Description / Specification:
EXFO IQ-1501 450 to 1100 nm Optical Power Meter Module

The Exfo IQ-1501 is a single-channel, high-accuracy calibration optical power meter module configured with a temperature stabilized silicon (Si) optical detector.
Specifications.
Spectral Range: 450 nm to 1100 nm.
Dynamic Range: +5 to -60 dBm.
Uncertainty at Specific Wavelengths: ± 1%1.
Uncertainty over Full Spectral Range: ± 1.5%2.
Display Resolution: 0.001 dB / 1 pW.
Linearity: ± 0.02 dB from - 10 dBm to -50 dBm3.
Spectral Resolution: 0.01 nm.
Applicable Fiber Type: 5/125 µm to 100/140 µm N.A. ≤ 0.3.

1. ±1% uncertainty at certain fixed wavelengths if calibrated at NlST under NISTreference conditions:
- absolute power of -10 dBm (100 µW), CW
- fiber type of 9/125 µm, 50/125 µm, or 62.5/125 µm (B, C, or D)
- connectors: FC, ST, SC, SMA, or HMS-I0
- FOA used at NIST
- source spectral width under I0 nm
- ambient temperature of 23°C +5°C

2. ±1.5% uncertainty if calibrated at NIST under the following reference conditions:
- absolute power between -10 dBm to -50 dBm (I00 µW to I0 nW), CW
- fiber type used in 1.
- connector used in I.
- FOA used in 1.
- source spectral width under 10 nm
- ambient temperature of 23°C +5°C

3. At constant temperature of ±1°C; ±0.01 dB from -15 dBm to -50 dBm.





Standard Calibration $720.00 *
Click on Logo for More Prices
*This is a Web introductory price for one calibration of the EXFO IQ-1501. Price does not in most cases include measurement performance data. Pricing does include NIST traceable calibration and issue of a calibration certificate and calibration label. Pricing may vary slightly due to volume and location of laboratory supporting calibration. Volume pricing may apply. On-site fees may apply depending on logistics, location and volume of work to be completed during the visit.


Related Optical Terms and Definitions. For a complete list go to our  Terms and Definitions Page.

Chromatic Dispersion
Chromatic Dispersion is a broadening of the input signal as it travels down the length of the fiber. Chromatic Dispersion results from a variation in propagation delay with wavelength, and is affected by fiber materials and dimensions.

Detector
A Detector is a signal conversion device that converts power from one form to another, such as from optical power to electrical power

Jitter
Jitter in technical terms is the deviation in or displacement of some aspect of the pulses in a high-frequency digital signal. Jitter is the time variation of a periodic signal in electronics and telecommunications, often in relation to a reference clock source. Jitter may be observed in characteristics such as the frequency of successive pulses, the signal amplitude, or phase of periodic signals. Jitter is a significant, and usually undesired, factor in the design of almost all communications links (e.g., USB, PCI-e, SATA, OC-48). In clock recovery applications it is called timing jitter.

Polarization Mode Dispersion (PMD)
Polarization mode dispersion (PMD) is a form of modal dispersion where two different polarizations of light in a waveguide, which normally travel at the same speed, travel at different speeds due to random imperfections and asymmetries, causing random spreading of optical pulses. It is he difference between the maximum and minimum values of loss typically measured in ps/km^1/2.

Please contact us for your EXFO IQ-1501 CALIBRATION and/or EXFO IQ-1501 450 to 1100 nm Optical Power Meter Module REPAIR
