Custom-Cal has been successful in repairing 100’s of OmniBer 718 units. We have a high success rate and can accommodate repairs of all types ranging from fan replacement to optical interface repair. We stock a wide range of parts as well as complete units ready for sale or rental. We specialize in quick turnaround times and we can handle expedited deliveries upon request.

Monthly Rentals at $1200 or Less, depending on configuration.

Self Test Errors:
  First digit indicates the Test being run. Digit nn is the subtest, if >99 the numbering restarts. Last digit indicates error type (use 2nd table).
Main Test CPU 1nnx
01 Flash ROM CRC checks
02 Ram Test
03-07 Not used
08 In-Lid Printer present check, (if option 602 fitted)
09 Not used
10 Floppy disk write/read
11 Not used
12-16 Front Panel processor checks
Main Test CONFIDENCE 2nnx
01 PDH 140 Mb/s Structured 64 kb/s
02 PDH 2 Mb/s 120 ohm balanced
03 PDH 34 Mb/s Structured 64 kb/s
04 PDH DS1, D4 Structured 64 kb/s
05 SDH, STM-0e Test
06 SDH, STM-0o Test
07 SDH, STM-1e Test
08 SDH, STM-1o Test
09 SDH, STM-4o Test
10 SDH, STM-16o Test
11 OPT 200 Jitter Test, PDH 34 Mb/s
12 OPT 200 Jitter Test, SDH 622 Mb/s
Main Test PDH 3nnx (for Subtests < 100), 18nnx (for Subtests 100+)
01-07 Line Code Tests (140/34/8/2 MHz Unable 75 ohm)
08-09 Line Code Tests (2 MHz Balanced 120 ohm)
10-21 Frequency Offset (140/34/8/2 MHz)
22-36 Error Add/Detect (34/2 MHz)
37-44 Framing (140/2 MHz)
45-53 Structured Payloads (140/34/8 MHz)
54-63 Patterns (140/34/8 MHz)
64 Drop/Insert (2 MHz)
65-72 Round Trip Delay (64 kb/s)
73-82 Not used
83-86 Line Code Tests (DS3/DS1 Unable 75 ohm)
87-88 Line Code Tests (DS1 Balanced 110 ohm)
89-94 Frequency Offset (DS3/DS1)
95-112 Error Add/Detect (DS3/DS1)
113-120 Framing (DS3/DS1)
121-130 Structured Payloads (DS3/DS1)
134-140 Patterns (DS3/DS1)
141 Drop/Insert (DS1)
142-145 Round Trip Delay
146-148 DS1 Unbalanced Tx/Rx tests
149-150 DS3 Unbalanced Tx/Rx tests
Main Test BER 4nnx
01 STM-16 MUX/DEMUX Internal Loopback
02-04 STM-0e Pulse Shape
05-08 Basic STM-0o Tx/Rx Test
07-08 Basic STM-1e Tx/Rx Test
09-10 Basic STM-1o Tx/Rx Test
11-12 Basic STM-4o Tx/Rx Test
13-14 Basic STM-16o Tx/Rx Test
15-17 STM-4o Frequency Measurement
18 STM-16o Frequency Measurement
19-20 Clock Reference Source
21-22 Optical Power Measurement
23 Overhead Byte Defaults [part 1]
24 Overhead Byte Defaults [part 2]
25 STM16o J0 Path Trace Message
26 J1 Path Trace Message
27 J2 Path Trace Message
28-35 SDH Error Add[RATE]/Detection
36-44 SDH Single Error Add/Detection
45 STM-16o Entire Frame Error Add/Detect
46 A1A2 Frame Error Add
47-49 PDH Payload Error Add[RATE]/Detection
50-52 PDH Payload Single Error Add/Detection
53-67 Alarm Generation/Detection
68-69 OOF Alarm Generation/Detection
70 TU-3/TU12 Mixed Payload Test
71 TU-12/TU-3 Mixed Payload Test
72 TU-3/TU-11 Mixed Payload Tests
73 TU-11/TU-3 Mixed Payload Tests
74-75 AU New Pointer Test
76-77 AU Frequency Offset Pointer Moves
78-79 TU Frequency Pointer Moves
80-81 STM-16o 140 Mb/s Payload VC Offset Test
82 TU-3 Background Pattern Test
83 DCC Port Test
84-87 Stress Test
88-99 Service Disruption Test
100-122 TCM Error Add/Detection
123-134 TCM Alarm Generation/Detection
135-137 TCM APId Message
Main Test JITTER 5nnx (for Subtests<100, 20nnx (for Subtests 100+)
01-02 Jitter Receiver Internal Loopback tests
03-47 Jitter Filter tests
50 Jitter PLL test
51-53 2Mb/s Tx/Rx Jitter Tests
54-56 8Mb/s Tx/Rx Jitter Tests
57-59 34Mb/s Tx/Rx Jitter Tests
60-62 140Mb/s Tx/Rx Jitter Tests
63-64 STM1e Tx/Rx Jitter Tests
65-66 STM1o Tx/Rx Jitter Tests
67-68 STM-4 Tx/Rx Jitter Tests
69-70 STM-16 Tx/Rx Jitter Tests
71-73 DS1 Tx/Rx Jitter tests
74-76 DS3 Tx/Rx Jitter tests
77-78 STM-0E Tx/Rx Jitter tests
79-80 STM-0O Tx/Rx Jitter tests
81-102 Not used
103-108 2Mb/s Tx/Rx Jitter Tests
109-114 8Mb/s Tx/Rx Jitter Tests
115-120 34Mb/s Tx/Rx Jitter Tests
121-126 140Mb/s Tx/Rx Jitter Tests
127-132 DS1 Tx/Rx Jitter tests
133-138 DS3 Tx/Rx Jitter tests
139-144 STM-0E Tx/Rx Jitter tests
145-150 STM-0O Tx/Rx Jitter tests
151-156 STM1e Tx/Rx Jitter Tests
157-162 STM1o Tx/Rx Jitter Tests
163-168 STM-4 Tx/Rx Jitter Tests
169-174 STM-16 Tx/Rx Jitter Tests
175-177 Wander Tests
178 Transfer Test 155 Electrical
179 Transfer Test 2M
180 Transfer Test 2.5G
Main Test LONG GATING 6nnx
01 Tx/Rx STM-0o with Bulk 2^23 Payload
02 Tx/Rx STM-1o with Bulk 2^23 Payload
03 Tx/Rx STM-4o with Bulk 2^23 Payload
04 Tx/Rx STM-16o with Bulk 2^23 Payload
Main Test ATM 7nnx
01-14 Basic Path Integrity
15-32 Header Generation & Filtering
33-41 Tx 2.4Gb/s Regeneration
42-47 Tx/Rx Pointer Processing
48-51 Alarm Add and Detection
52-64 Error Add and Detection
65-77 Test Cell Generation & Synchronization
78 34M G832 Trail Trace
79-81 Jitter Tolerance
Main Test POS 8nnx
01-14 Basic Path Integrity
15-23 Random Packet/Gap Data/Clock Path Integrity
24-33 Alarm Add and Detection
34-43 Error Add and Detection
44-53 Packet Rate
54-55 Jitter Tolerance
Error Code Last Digit (indicates the error type)
1 Loss of Signal
2 specific for subtest
3 test result too low
4 test result too high
5 loss of frame sync
6 loss of pointer sync
7 loss of pattern sync


Instrument Options:
001 SDH (ITU-T) Test
002 Dual standard SONET/SDH (ANSI/ITU-T)
010 Structured PDH 2/8/34/140Mb/s
011 DSN/PDH Rates DS1/DS3/E1/E3
012 PDH/T-carrier DS1, DS3, 2 Mb/s, 8 Mb/s, 34 Mb/s & 140 Mb/s
014 2 Mb/s into DS3 mapping (also requires option 012)
104 Optical interface 1310 nm only
105 Optical interface 1550 nm only
106 Optical interface Dual wavelength 1310 nm/1550 nm
200 Adds jitter Tx/Rx capability to all selected rates
204 2.5G Multi-rate 1310nm BER + Jitter
205 2.5G Multi-rate 1550nm BER + Jitter
206 2.5G Multi-rate 1310/1550nm BER + Jitter
210 Adds optimized jitter receiver intrinsics(requires opt 200)
300 ATM payloads(up to highest rate)(requires option 350/355)
310 POS payloads(up to highest rate)(requires option 350/355)
350 Advanced payload engine, Provides additional necessary hardware for ATM and POS
355 Advanced payload engine, providing service disruption history and timestamping and AIS measurements on optical signals to highest rate (must be included for ATM (opt 300) and/or POS (opt 310))
600 Remote Omnibook controller
601 RS-232-C, GPIB and LAN remote control interfaces
602 80-column in-lid graphics printer
610 Optical interface replaces FC/PC adapters with SC (B/C only)
611 Optical interface replaces FC/PC adapters with ST (B/C only)
620 Replaces BNC connector with WECO 560
Description of Model
The main features of a dual standard (SDH/SONET) instrument are as follows:
• Multi-rate BER and jitter testing (opt 200) from 64 kb/s to 2.5 Gb/s (STM-16/OC-48).
• Concatenated payloads at all synchronous rates up to 2.5 Gb/s
• Full PDH/T-carrier testing.
• Direct measurement of protection switching time.
• Powerful thru-mode testing for SDH/SONET ring turn-up.
• Comprehensive SDH/SONET overhead testing.
• Packet over SONET/SDH (POS) and ATM payloads up to 2.5 Gb/s.
• Fast access to key measurement tasks via Smart Test.
• Optical power and line frequency measurements.
• J0 section trace for DWDM testing
• J1 and J2 path trace for network path testing
• Optional integrated graphical printer
• Line frequency offset
• Transmit and Receive can be independently configured.
